Johnson & Evinrude 1995-2006 75-115 HP 60° Small Foot Outboard Gearcase Parts Diagrams

This page features a comprehensive selection of lower unit components for Johnson & Evinrude 4-cylinder 60° Small Foot outboard engines, covering 75 to 115 HP models built between 1995 and 2006. Whether you're restoring or rebuilding your lower unit, you'll find OEM-equivalent parts from Red Rhino, EMP, & RecMar, including propshafts, bearings, seal kits, anodes, and rebuild kits. Ideal for marine technicians and DIY enthusiasts seeking reliable, high-quality components for maintenance and repair of Johnson & Evinrude V4 outboards.

The following parts correspond to the numbers on the diagram above:

1. Driveshaft Thrust Bearing
2. Pinion Bearing
3. Forward Thrust Bearing
4. Reverse Thrust Bearing
5. Reverse Gear Bearing
6. Propshaft Bearing
7. Bearing Housing, Pin & Spring
8. Pinion Nut
9. (Not Pictured)
10. Clutch Dog
11. Clutch Dog Spring
12. Clutch Dog Pin
13. Driveshaft Thrust Washer
14. Forward Thrust Washer
15. Reverse Gear Thrust Washer
16. Gear Set
17. Upper Driveshaft 20"
18. Propshaft
19. Lower Driveshaft
20. Driveshaft Shim, .003, Shim Kit
21. Anode Block Gearcase
22. Bearing Carrier Zinc Anode
23. Bearing Carrier
24. Retainer Tab Bearing Carrier
25. Crankshaft/Propshaft Seal
26. Shift Lever, Bearing Housing
27. Shifter Shaft
28. Shift Cradle
29. (Not Pictured)
30. Shift Lever Pin
31. Driveshaft Retainer
32. Driveshaft Bearing O-ring
33. Driveshaft Bearing Housing
34. Driveshaft Oil Seal
35. Flat Blade Drain Screw, Drain Screw Gasket
36. Trim Tab - STD
37. Water Pump Kit w/Housing
38. Seal Kit

We also offer a complete Bearing Kit!
