Johnson & Evinrude 1979-2012 V6 150-250 HP Outboard Gearcase Parts Diagrams

This page features a comprehensive selection of Johnson & Evinrude V6 gearcase parts and rebuild kits for 150–250 HP models produced between 1979 and 2012. Whether you need gear sets, driveshafts, bearing kits, thrust washers, prop shaft components, or seal kit assemblies — OBParts delivers high-performance, reliable parts to maintain and rebuild your gearcase. Designed for both DIY mechanics and professionals, each product is carefully categorized by model, OEM number, and application, making it simple to find the right component for your specific outboard engine needs.

The following parts correspond to the numbers on the diagram above:

1. Driveshaft Thrust Bearing
2. Pinion Bearing
3. Forward Thrust Bearing
4. Reverse Thrust Bearing
5. Reverse Gear Bearing
6. Rear Carrier Bearing
7. Shift Housing w/Bearing
8. (Not Pictured)
9. Clutch Dog
10. Clutch Dog Spring
11. Clutch Dog Cross Pin
12. Gear Set (1979-1991), or (1992-2012)
13. Upper Driveshaft - (1991 & Older, L, 20"), (1991-2006, 60° L, 20"), (1992-2006 Looper, L, 20"), (1991 & Older XL, 25"), (1986-2007 60° XL, 25"), or (1992-2006 Looper XL, 25")
14. Lower Driveshaft
15. Propshaft
16. Driveshaft Thrust Washer
17. Forward Thrust Washer
18. Reverse Gear Thrust Washer
19. Pinion Nut
20. Driveshaft Bearing Housing
21. Bearing Carrier
22. Bearing Carrier Retainer Tab
23. Bearing Carrier Zinc Anode
24. Propeller Thrust Washer
25. Propshaft Oil Seal
26. Lower Unit Lever
27. Shifter Shaft
28. Shift Cradle
29. Driveshaft Pin
30. Driveshaft Retainer
31. Shim Kit
32. Driveshaft Bearing O-ring
33. Driveshaft Oil Seal
34. Water Intake Screen
35. Drain Screw Gasket
36. Trim Tab - STD
37. Block Gearcase Anode
38. Water Pump Kit w/Housing
39. Seal Kit
40. Prop Nut Spacer
41. Prop Nut and Spacer Kit
42. Cotter Pin

We also offer a complete 1979-1991 Bearing Kit or 1992-2012 Bearing Kit!
