Johnson & Evinrude 1995-2006 V4 60 Degree & Ficht 75-115 HP Powerhead Parts Diagrams
This dedicated parts page features a comprehensive selection of OEM and aftermarket components for Johnson & Evinrude V4 60° & Ficht outboard motors ranging from 75 to 115 horsepower, covering model years 1995 through 2006. Whether you're rebuilding the powerhead, servicing the crankshaft assembly, or replacing cooling system parts, you’ll find everything from thermostats, gasket sets (carbureted and Ficht-specific), O-ring kits, piston and ring sets, bearings (rod, wrist pin, center main), crankshaft seal kits, trim motors, starters, solenoids, and more—all designed for precision fit and dependable performance. Ideal for DIY mechanics, professional marine technicians, and dedicated restorers seeking reliable components for Evinrude engines.
The diagram above is for a Johnson & Evinrude V4 60° & Ficht 75-115 HP Powerhead Assembly from 1995 to 2006. The following parts correspond to the numbers on this diagram:
We recommend the following kits for this powerhead:
- Carburetor Kit
- Gasket Set
The diagram above is for a Johnson/Evinrude V4 60° & Ficht 75-115 HP Crankshaft Assembly from 1995-2006. The following parts correspond to the numbers on this diagram:
- Wrist Pin Bearings
- Rod Bearings
- Center Main Bearing
- Lower Crank Bearing
- Rod Bolts
- Crankshaft Seal Kit
- Lower Seal Housing
We recommend the items below for this motor:
